Electrotherm Solar Power House

  Solar Power House (SPH) is a consolidated smart solution of DC inverter circuit and AC power circuit placed together under the same roof confined in a thermally insulated outdoor container. The combined solution can easily be transported to a solar park and generate MW capacity of power in no time. Due to the extremely poor availability of resources at the remote villages where the solar park is usually located, the supply of sensitive instruments like power inverter and associated power products and control instruments and their respective power and control cable connections are not only a challenge in today’s world but needs skilled labor and substantial integration time. Due to this, site integration of control and instruments becomes a daunting task in solar field. Moreover, on completion of terminal connections of various instruments, each of them needs to be tested to ensure overall equipment performance. Thus it is highly difficult to get required amount of output at site within an extremely tight project completion schedule.  Electrotherm having its strong R&D background in solar inverter transformer and solar EPC solutions with its state-of-the-art manufacturing facility in Gujarat for power and various other transformers has taken the initiative to introduce its most reliable and smart substation solution to cater to solar power generation industries which help solar industries to build power stations in record time. The solution is just a plug and play device. These robust and high-tech container solutions are easy to ship and commission at remote site without any dependence on skilled manpower or equipment suppliers. Each AC and DC container together with associated auxiliary equipment can handle power up to 2.5 MW within a smart dimension of L (11,000 mm) X B (2,800 mm) X H (3,200 mm). The DC container accommodates solar inverters of reputed make along with separate standalone SCADA solution.  The factory-built product is completely integrated and tested in combination with DC circuit and the AC circuit before shipment which is the biggest challenge in any solar project. It also helps reducing the integration cost at site and dependency on so many agencies. There is an add-on advantage attached to it, all the critical components are pre mapped in the container solution to make it fail safe and accordingly Alarm and Trip circuits are designed and signals are wired up to the SCADA panels which then send the hierarchy signal to central SCADA server for preliminary data management and necessary proactive actions. With intelligent door devices and smart communication facility, the SPH helps customer to know about each container power output with a time axis while sitting at a remote distance.
With the age old experience in reliable transformer design and manufacturing, ET selects the right design of low-loss solar inverter transformers integrated with high-class HT switch gear to provide a very efficient and reliable AC circuit to handle the MW power flow up to the grid in a compact and reliable manner while controlling and monitoring the DC connection continuously to record the Inverter DC power flow in to the cubicle. The supporting circuits for reliable operation of inverters backed up with battery and UPS make the customer free from arranging resources to complete the integration. Therefore, SPH is an independent and preferred solution which helps customer to build and operate several MW capacity solar park within a shorter time frame. The biggest advantage is that all under one roof and no connection to be done at site. According to Electrotherm (India), this is a compact solution as against conventional substation which involves huge cabling work at site and dependence on many agencies. It not only helps the customer to avoid civil work at site but also helps to avoid HT cable laying and termination work, LT cable laying and termination work, DC cable laying and termination work, inverter DC and AC cable connection, transformer installation and cable termination, installation and connection of HT panels etc. etc. For a typical 50 MW power plant, client needs to just order out 20 such containers to ship at site which can then be integrated with PV modules already installed and connected at site to their respective combiner boxes, Electrotherm (India) informs. The single-window solution also extends up to site commissioning assistance to help customer commission the power plant without any hurdle. ET solar team also offers complete turnkey solution up to 300 MW single solar park.
Contact:Electrotherm (India) Ltd.72, Palodia (via Thaltej), Ahmedabad – 382 115Tele: +91-2717 660550 E-mail: tinfo@electrotherm.com
