Diesel fuel consumption: Control it, reduce it and save!

November 23, 2016 11:40 am

EPR (Electrical & Power Review) | EPR Magazine

  Flow Measurement of diesel fuel is a relatively basic flow meter application. However, measuring net fuel consumption on a diesel generator is uniquely complex. The diesel engine requires a supply fuel line (fuel from the tank to the engine) and a return fuel line (fuel from the engine back to the tank). The net fuel consumed is the difference between the fuel supply and the fuel return, a measurement which requires two flowmeters. This method is not limited to diesel engines. In fact, nearly any type of burner using a liquid fuel will have this supply/return method, for example, black liquor recovery boilers in paper mills and other boilers burning liquid fuels.
ApplicationIn diesel powered generators the supply and return flow rates are usually measured by a positive displacement type flowmeter providing a pulse output.
SolutionTwo Oval Wheel Flow meters were installed; one on the fuel supply line and one on the fuel return line. The return line meter was mounted on the building wall near the fuel tank, but for convenience the supply unit was mounted on an engine accessory rack next to the diesel engine. During operation there is vibration from the diesel engine, but the oval wheel flow meters design work un-affected eliminating any issues resulting from these vibrations. The new generation electronics takes the pulses from the flow sensor S and flow sensor R giving a resultant difference (fuel consumed) on the display.
Also available are flow meters for tanker unloading.
ContactToshniwal Hyvac Pvt Ltd267 Kilpauk Gardens Road, Chennai – 600 010Tele: +91-44-26445626/8983Email: sales@toshniwal.net  www.toshniwal.net
