MECO “transformer turns ratio metre model: TTR-8100”

June 5, 2023 1:58 pm

MECO “transformer turns ratio metre model: TTR-8100”

The transformer is a very important element in the electric power distribution system. It needs to be maintained from time to time so that the power distribution system can be further guaranteed at the consumer end.

The MECO Transformer Turns Ratio Metre Model TTR-8100 is used for accurate measurement of 1/3-phase transformers. It displays the turn ratio, deviation, secondary output, excitation voltage and current, phase angle, and nameplate transformer/VT/CT values on one page for easy quality interpretation. It is used for checking live test points, short circuits, open circuits, and reverse polarity before each measurement. builtin memory to store 4096 measurement data files (with date and time). Wireless Blue Tooth for transferring recorded data to a PC or laptop.

Portable, handy, lightweight, and userfriendly operation are key features of the MECO Model TTR-8100. The user needs to follow the graphical and literal illustrations on the large back-lit dot matrix LCD to make the winding connection. If the transformer is live with voltage or has the wrong winding connection, it will warn the user. Measurement range: VT/PT Ratio 8–10000 and CT Ratio 0.8–2000, with an accuracy of 0.1percent. Userprogrammable RCF (Reference Connection Factor 0.99–1.01 to correct accuracy within 1percent error)

Supplied with accessories: a set of test leads, alligator clips, a powerful lithium battery (built-in charging circuit), an AC adaptor, a power cord, a carrying bag, a PC application software CD, and a manual.

For details, please visit our website: www.mecoinst.com
Email: sales@mecoinst.com
